Single Vacuum Transformer Oil Purifier
Single vacuum transformer oil purifier is suitable for processing unqualified transformer oil, mutual inductor oil, switch oil, insulating oil
Download
Description
Product Parameter
| Parameter | Unit | ZL-10 | ZL-20 | ZL-30 | ZL-50 | ZL-100 | ZL-150 | ZL-200 | |
| Flow Rate | L/min | 10 | 20 | 30 | 50 | 100 | 150 | 200 | |
| Fine Filter | μm | ≤5 | |||||||
| Vacuum Degree | Mpa | -0.06 ~-0.095 | |||||||
| Working Pressure | Mpa | ≤0.5 | |||||||
| Working Temperature | ℃ | 30~80 | |||||||
| Power Supply |
| 380V 50Hz 3 Phase 4 Wire (Can be customized) | |||||||
| Working Noise | dB(A) | 61 | 63 | 65 | 70 | 75 | 78 | 80 | |
| Heating Power | KW | 15 | 18 | 24 | 36 | 60 | 81 | 90 | |
| Total Power | KW | 18 | 21 | 27 | 39 | 65 | 86 | 98 | |
| Inlet(Outlet)Diameter | mm | Φ25 | Φ32 | Φ32 | Φ32 | Φ42 | Φ48 | Φ60 | |
| Net Weight | Kg | 150 | 200 | 260 | 300 | 500 | 700 | 900 | |
| Overall Dimensions | L | mm | 1050 | 1100 | 1150 | 1200 | 1600 | 1600 | 1800 |
| W | mm | 700 | 850 | 900 | 950 | 1000 | 1100 | 1200 | |
| H | mm | 1300 | 1400 | 1450 | 1500 | 1700 | 1800 | 1850 | |
Product Feature And Application
Three-dimensional flash, efficient dewatering, degassing.
Mesh filter and purify the combination of polymer adsorption technology.
It has dual infrared liquid level control.
Trinity interlock protection device.
The machine can be used independently, can also be used in conjunction with the oil regeneration system.
The machine can be insulating oil for transformers and other electrical equipment vacuum oiling, vacuum drying.
Random testing can withstand voltage and automatically print test results (ZYA series).
The machine can be charged online operation.
Production Details
| 1 | Solenoid | 13 | Aeration valve | 25 | oil pump motor |
| 2 | Bypass-Valve | 14 | Fine Filter | 26 | Buffer tank |
| 3 | Vacuum Separator | 15 | Vacuum Gauge | 27 | Vacuum valve |
| 4 | Heater | 16 | Vacuum valve | 28 | water tank |
| 5 | 1st -Stage Filter | 17 | Condenser | 29 | Vacuum pump |
| 6 | 2 st -Stage Filter | 18 | warning Light |
|
|
| 7 | Oil glass observation | 19 | Heat exchanger |
|
|
| 8 | Check valve | 20 | Pressure Gauge |
|
|
| 9 | Inlet Valve | 21 | Temperature controller |
|
|
| 10 | outlet Valve | 22 | Pressure Controller |
|
|
| 11 | Circulation valve | 23 | Control Button |
|
|
| 12 | Observation Mirror | 24 | Nameplate |
|
|
Product Qualification
Deliver, Shipping And Serving
Pre-sale service
1. We have stock and can deliver within short time.
2. OEM and ODM order are accepted, Any kind of logo printing or design are available.
3. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
4. All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
After-sale service
1. We are very glad that customers give us some suggestion for price and products.
2. If you have any question,please contact us freely by E-mail or Telephone.
FAQ
Q1,:What’s the application scope of Screw press machine?
A1: It is widely applied in wastewater treatment in industrial, chemical, municipal and so on.
Q2: How can I get the bottom price?
A2: The price marked is already the best price for you.
Q3: How long will it take to receive my product?
A3: In general, it will take you 10-15 days to get it.
Q4: What payment methods can I use?
A4: Currently, you can pay via L/C,Western Union,T/T(bank transfer),Paypal, MasterCard
Q5: Customer Service:
A5: Please contact us any time when you have questions or problems upon our products. Your inquiry will be replied within 24 hours
