Automatic Water Softener Treatment

Automatic water softener treatment is through sodium ion exchange softening of water. When raw water passes through sodium ion exchanger, Ca 2+, mg 2+ in water is replaced by Na + in the exchanger, so that scalable Ca and Mg compounds can be transformed into soluble sodium compounds without scaling and water can be softened. Free calcium, magnesium and bicarbonate ions in water are packaged into nanocrystals to prevent scale formation.

Get A Quote

Download

Share to

Description

Product Parameter



Product Name

automatic water softener treatment

Water Pressure

0.2-0.6MPa

Water Temperature

5℃-50℃

Water Turbidity

<5FTU

Inlet/Outlet

2"M

Drain

1.5"M

Base

4"-8NPSM

Riser Pipe

1-1/2"D-GB or 1.9"OD

Max Flow Rate

15 m3/h

Suitable Tank Size (in)

30~40"



Product Feature And Application



  1. Indication of long time power cut, data saved after power off (Saved for three days).
  2. No hard water bypass in rising cycle.
  3. Remote handling connector b-01 (02).
  4. Backwash, fast rinse frequencies setting F-00, service one time, backwash and fast rinse several times.
  5. Remote signal input connector.
  6. Interlock function for contemporary system and individual rising.
  7. Start rising by days or hours.
  8. Time type or meter type is for optional.



Production Details



Function

Soften hardness water

Warranty

1 Year.

Liner

PE / ABS

Opening

TOP & BOTTOM

Max. Operating Pressure

100-150PSI

Operating Temprature

34-122 °F(1-50 °C)



Product Qualification




Delivery, Shipping And Serving



  1. OEM acceptable
  2. Sample order
  3. 100% QC inspection before shipping
  4. We will reply you in 24hours
  5. 180 days guarantee time
  6. Best after-sale tracking service



FAQ



Q: Are you trading company or factory?

A: We are factory.



Q: How Does Reverse Osmosis Work?

A: Reverse osmosis systems purify water by forcing pressurized water through a very fine, plastic membrane. If the raw water being treated comes from a well or another private source, disinfection and pre-filters (to remove chlorine and/or particulates/sediment) may be needed in advance of the R/O unit to remove contaminants that can foul or damage the membrane.



Q: How Do I Know What Size Unit to Buy?

A: R/O units are rated according to the amount of treated water produced per day. For example, one type of unit produces 5000 liters of treated water per day under its design conditions. In reality, conditions frequently vary. Line pressure is often lower, water will frequently be colder than 25° C and backpressure in the storage tank will likely reduce the performance of the unit.

Consequently, you should examine water conditions and buy a larger rated unit than needed if any of the above problems are noted



Q: Material of the reverse osmosis system?

A: You can choose FRP filter + U-PVC pipe, stainless steel filter + U-PVC pipe or total stainless steel.

Download

After-sales Service

One year guarantee for producing high quality (People-damaged components are charged).

Lifelong spare parts supply.

Highly design customized products according to customer requirements.

Free training on equipment installation and operating procedures for your employees.

Company Introduction

  • Chongqing Meiheng Electric & Machinery Co., Ltd. and Chongqing Meiheng Industrial Purification Equipment Factory were founded in 2003 and are located in Shaping District, Chongqing. The company is a high-tech enterprise specializing in R&D, design, manufacture and sale of various petroleum purification equipment, water treatment system equipment and chemical feeding machinery.

Packaging Details: wooden case
Delivery Time: within 30 working days after order confirmation
