YJF Coalescing And Separation
- 100 lpm factory price movable steam turbine coalescence separation lube oil purifier machinery fuel oil purifier.
- Coalescing dehydration oil purifier integrates two functions of precision filtration and high-efficiency dehydration. It uses advanced "coalescence separation" technology for dehydration, with high dehydration efficiency and strong capacity. It is especially suitable for separating large amounts of water in oil. It has the incomparable advantages of vacuum method and centrifugal method.
Download
Description
It can break all the oil-water emulsification structure in the medium: through the filtration of the particle filter system, the cleanliness of the medium can be stably controlled to the state required by the system to ensure the cleanliness of the oil: the physical and chemical properties of the oil are not changed.
Extend the service life of the oil wave: low energy consumption.
Low operating cost; excellent system configuration, strong continuous working performance, suitable for online operation.
The coalescing dehydration oil purifier has a five-stage filter system.
The first stage suction filter, in the coarse filter at the suction port, protects the oil pump and prolongs the service life of the main filter.
The second-stage pre-filter is located upstream of the coalescer, which can extend the life of the coalescer and reduce the content of particles in the filtered liquid.
The third stage coalescing filter causes the water in the oil to condense and sink.
The fourth-stage separation filter further blocks the tiny water droplets in the oil to achieve efficient separation.
The fifth-level fine filter adopts a filter medium with high precision and large dirt holding capacity, which can purify oil safely and efficiently.
